Description
| Brand | Echo |
| Engine Type | Hybrid 4-stroke, air-cooled, single cylinder |
| Engine Displacement (cc) | 36.3 |
| Net Rated Power Output | 1.4kW / 1.9ps |
| Start Method | Recoil |
| Ignition System | CDI, digital megneto |
| Start Assist System | Decompression valve |
| Carburettor | Diaphragm, ZAMA RB-110137B |
| Spark Plug | NGK CMR5H |
| Fuel Tank Capacity (L) | 0.85 |
| Fuel / Oil Mixture | 50 : 1 (premixed alkylate fuel for 2-stroke can be used) |
| Fuel Consumption | 0.92l/h |
| Gear Reduction Ratio |
1 : 1.62 |
| Cutting Diameter | 510mm / 20″ |
| Brush Cutter Blade | No |
| Nylon Line Head | Z5 M10L (EA-X047-000332) |
| Line Diameter | 3.0mm, SilentSpiral |
| Length of Cord | 5.0m |
| Line Feed | Tap & go |
| Rotating Direction | Counterclockwise as viewed from top |
| Shaft Type | Straight, solid |
| Outer Shaft Diameter | 25mm |
| Drive Shaft Diameter | 7mm |
| Handle Type | Cowhorn |
| Handle Type | Front: D-loop Rear: Throttle handle |
| Harness | Shoulder, C062-000511 |
| Vibration – Grass Trimmer Attachment | Left handle: 4.7m/s / Right handle: 3.4m/s |
| Sound and Noise Data | Sound pressure level: 93.8dB(A) / Sound power level: 107.6dB(A) |
| CO² | 832g/kW.h |
| Assembled Dimensions | L: 1806mm x W: 646mm x H: 569mm |
| Weight (kg) | 6.3 |
| Warranty | Manufacturer’s – 5 years consumer, 2 years commercial (subject to registration within 30 days) |
